How to install curved curtains for corner windows

A

Unpack your kit, and gently lay it all out on a clean, hard surface or the cardboard packaging it came in.

B

Lay your track(s) near your corner window to check the width and make note of where it will be installed.

For 2 or more pieces of track, lay your track joiner(s) on the floor and click an end of two tracks into it, so the ends meet in the middle of the track joiner. Repeat for each joiner until you have joined all your tracks. If the length of a straight edge of your track is over 3 metres you will have 2 or more pieces of track.

C

Check how many brackets you need for your track width. Lay out the brackets next to your track and space them 600 mm apart. This is the standard distance between ceiling battens.

Corner brackets need to be at least 60 mm out from corners. For heavy, blockout curtains it's important to have a bracket near the corner(s) for a 90 degree track.

For 2 or more pieces of track, you'll also need two brackets on either side of the track joiner(s). Lay out these brackets at least 85 mm apart, as the joiner is 85 mm long.

A

If you have ceiling battens that run lengthways use your stud finder to find your ceiling battens. Make a pencil mark on each ceiling batten that your curtains will cover, 35 mm out from your walls or out from any window frames or roller blinds that project out. These marks are where the back of your brackets will line up.

Your brackets will screw into your ceiling battens, and you'll need brackets near both ends and the middle of your track.

B

If you have ceiling battens that run widthways use your stud finder to find the ceiling battens that your curtains will hang from, and make pencil marks along the battens. The back of your brackets needs to be at least 35 mm out from your wall on each side.

Your brackets will screw into your ceiling battens, and you'll need brackets near both ends and the middle of your track.

C

Can't find ceiling battens? Don't stress! Ceiling battens are the best surface to attach curtains to, so call us if you need some help finding your battens. Remember you can use plaster wall anchors if you can't find your ceiling battens.

Screwing into concrete, stone, brick or tile? You can skip this step completely.

A

Clip your corner bracket(s) onto your track near the track curve(s). Make sure the track is completely straight where you clip on the bracket(s).

Remember you need a bracket near each 90 degree corner for heavy, blockout curtains.

B

Hold your track up onto your ceiling with the 90 degree curve(s) in your corner(s). Grab a pencil and mark exactly where your corner bracket(s) will attach to your ceiling. This will ideally be onto your ceiling battens.

If your track wraps around a corner follow the same steps to clip on your corner bracket(s) and mark its position on your ceiling.

Once you've marked up your corner bracket(s) unclip your bracket(s) so you can screw it onto your wall.

A

Position the back of each bracket in line with the pencil marks on your ceiling battens, and mark the screw holes with a pencil.

For 2 or more pieces of track, don't mark up and screw in your middle brackets either side of the track joiner(s) just yet.

B

Using your protective eyewear and your cordless drill with the 3 mm drill bit, drill each hole. Look for wood shavings as a sign that you're drilling into the ceiling battens.

C

Screw your brackets part way into your ceiling so they're still a bit loose, using your cordless drill with the Phillips head drill bit and the screws in your custom kit.

Using plaster wall anchors or screwing into concrete, stone, brick or tile? Call or email us for guidance on attaching to different surfaces.

A

Pick up your track and lift it into position with the 90 degree curve(s) in your corner(s) and the track lining up to your brackets. Click the track into the middle bracket(s).

B

Tighten the screws in your middle bracket(s) using your cordless drill, to fix the track in place.

Click your track into the other brackets and tighten the screws, checking as you go that the track is fixed securely in place.

C

For 2 or more pieces of track, lift your joined track into position with the 90 degree curve(s) in your corner(s) and the track lining up to your brackets. Click your joined tracks into all your brackets. Then pick up your middle brackets and place them either side of your track joiner(s). Mark up with a pencil where you'll attach them. This will ideally be onto ceiling battens.

Unclick your joined tracks and follow step 4 to screw in your middle brackets. Then follow step 5 to click your track back in to all brackets and secure it by tightening the screws.

A

Check the top of your curtain panels and make sure there's a pendant or hook attached to each press stud.

Missing a pendant or hook? Simply grab a spare pendant or hook from your custom kit and click it onto the press stud, where the pendant or hook is missing.

B

For S fold curtains, click each pendant into your track, starting at one edge. Take care not to miss any pendants. Make the S shape as you go, by folding the fabric alternately forwards then backwards.

If you ordered multiple curtain panels start at the left and attach each panel in the correct order (see labels on panels).

C

For pleated curtains, attach each hook into your track. Take care not to miss any hooks.

If you ordered multiple curtain panels start at the left and attach each panel in the correct order (see labels on panels).

A

Unpack your kit, and gently lay it all out on a clean, hard surface or the cardboard packaging it came in.

B

Lay your track near your corner window to check the width and make note of where it will be installed.

For 2 or more pieces of track, lay your track joiner(s) on the floor and click an end of two tracks into it, so the ends meet in the middle of the track joiner. Repeat for each joiner until you have joined all your tracks. If the length of a straight edge of your track is over 3 metres you will have 2 or more pieces of track.

C

Check how many brackets you need for your track width. Lay out the brackets next to your track and space them 600 mm apart. This is the standard distance between wall studs.

Corner brackets need to be at least 60 mm out from corners. For heavy, blockout curtains it's important to have a bracket near each corner for a 90 degree track.

For 2 or more pieces of track, you'll also need two brackets on either side of the track joiner(s). Lay out these brackets at least 85 mm apart, as the joiner is 85 mm long.

A

If your wall studs run lengthways, use your stud finder to find your wall studs. Make a pencil mark on each wall stud that your curtains will cover, at the exact height where your curtains will start. You can check back to the drop measurement you took.

Your brackets will screw into your wall studs and you'll need brackets near both ends and the middle of your track.

B

If your wall studs run widthways, use your stud finder to find your wall studs. Make pencil marks along the wall studs that your curtains will hang from, at the exact height where your curtains will start. You can check back to the drop measurement you took.

Your brackets will screw into your wall studs and you'll need brackets near both ends and the middle of your track.

C

Can't find wall studs? Don't stress! Wall studs are the best surface to attach curtains to, so call us if you need some help finding your studs. Remember you can use plaster wall anchors if you can't find your wall studs.

Screwing into concrete, stone, brick or tile? You can skip this step completely.

A

Clip your corner bracket(s) onto your track near each track curve. Make sure the track is completely straight where you clip on the brackets.

Remember you need a bracket near your 90 degree corner(s) for heavy, blockout curtains.

B

Hold your track up onto your wall with the 90 degree bend(s) in your corner(s). Grab a pencil and mark exactly where your corner bracket(s) will attach to your wall. This will ideally be onto your wall studs.

If your track wraps around a corner follow the same steps to clip on your corner bracket(s) and mark its position on your wall.

Once you've marked up your corner bracket(s) unclip your bracket(s) so you can screw it onto your wall.

A

Position the arm of each bracket in line with the pencil marks on your wall studs, and mark the screw holes with a pencil.

For 2 or more pieces of track, don't mark up and screw in your middle brackets either side of the track joiner(s) just yet.

B

Using your protective eyewear and your cordless drill with the 3 mm drill bit, drill each hole. Look for wood shavings as a sign that you're drilling into the wall stud.

C

Screw your brackets tightly into the wall using your cordless drill with the Phillips head drill bit and the screws in your custom kit.

Using plaster wall anchors or screwing into concrete, stone, brick or tile? Call or email us for guidance on attaching to different surfaces.

A

Loosen the screw in each bracket, marked A in the diagram.

B

Pick up your track and lift it into position with the 90 degree curve(s) in your corner(s) and the track lining up to your brackets. Click your track into each bracket. Tighten screw A on each bracket to fix the track into position and check that the track is secure.

C

You can adjust the position of your track to bring it closer to or further away from your wall. Loosen screw A on each bracket. Slide the track forwards or backwards then tighten the screws once you're finished.

D

For 2 or more pieces of track, loosen the screws marked A.

Pick up your joined track and lift it into position with the 90 degree curve(s) in your corner(s) and the track lining up to your brackets. Click your track into each bracket. Pick up your middle brackets and place them either side of your track joiner(s), then mark up with a pencil where you'll attach them. This will ideally be onto wall studs.

Unclick your joined tracks and follow step 4 to screw in your middle brackets. Then follow step 5 to click your track back in to all brackets and secure it by tightening each screw marked A. You can also adjust the position of your track by following step C.

A

Check the top of your curtain panels and make sure there's a pendant or hook attached to each press stud.

Missing a pendant or hook? Simply grab a spare pendant or hook from your custom kit and click it onto the press stud, where the pendant or hook is missing.

B

For S fold curtains, click each pendant into your track, starting at one edge. Take care not to miss any pendants. Make the S shape as you go, by folding the fabric alternately forwards then backwards.

If you ordered multiple curtain panels start at the left and attach each panel in the correct order (see labels on panels).

C

For pleated curtains, attach each hook into your track. Take care not to miss any hooks.

If you ordered multiple curtain panels start at the left and attach each panel in the correct order (see labels on panels).
